Product RU40U-M12-UPN8X2-H1141
Ultrasonic sensor
Diffuse-mode sensor
Order number: 100052189- Smooth sonic transducer face
- Cylindrical housing, M12, potted
- Connection via M12 × 1 male connector
- Teach range adjustable via connection cable
- Blind zone: 4 cm
- Range: 40 cm
- Resolution: 1 cm
- Narrow sonic cone
- Switching output, PNP/NPN, programmable
- NO/NC parameterizable
- IO-Link
Technical Data
| Design | Threaded barrel |
| Medium | liquids, Bulk goods |
| Detection type | contactless |
| Output function | NO/NC, PNP/NPN |
| Communication protocol | IO-Link |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Metal, CuZn, Chrome-plated |
| Ambient temperature | -25…+70 °C |
| Protection class | IP67 |
| Approvals | CE, cULus |
