Product FCS-M18-IOL-0.2-RS4T
Flow monitoring sensor for air flow
With integrated processing unit
Calorimetric measuring principle — immersion design
Order number: 100052050- Sensor for gaseous media
- Calorimetric functionality
- Chrome-plated brass sensor
- DC 3-wire, 24 VDC
- PNP NC/NO contact
- Parametrizable via IO-Link SSP 4.1.2
- 20-cm pigtail with M12 male connector
- 6-color LED red/yellow/green/cyan/purple/blue
General data
| EAN | 4047101695205 |
| eCl@ss-Code (V5.1.4): | 27273190 -/- Flow meter (not classified) |
| Customs tariff number | 90268020000 |
| Country of origin | DE |
| Weight | 111 g |
Technical Data
| Design | Immersion |
| Operating voltage | 18…30 VDC |
| Switching element function | NO/NC (NO pre-set) |
| Output function | PNP |
| Communication protocol | IO-Link |
| Electrical connection | Cable with connector, M12 × 1 |
| Cable length | 0.20 m |
| Process connection | M18 × 1 |
| Housing material | Metal, CuZn |
| Ambient temperature | -20…+70 °C |
| Protection class | IP67 |
| Approvals | UL |
Data Sheets
Approval/Declaration
Configuration File
Configuration Software
Manual
Quick Start Guide
